The smartest choice for exterior folding door hardware. New locking mechanism with no loose parts. The new push button locking mechanism is a stand-out element and is consistent across all hangers and pivots. It has no loose parts that can be misplaced during installation. Easy adjustment - For faster installation, the locking mechanism provides easy vertical. Featuring automatic locking technology, the system self locks as soon as the push button is released, ensuring that the panel always remains set.
Horizontal and vertical glazing bars are used to continue a uniform pattern where mullions or transoms have been fitted, it is also used create a Georgian style window by using a cross within each unit of glazing.
Leaded, 18mm, 20/26, mm60mm
Obscure glass is used for front doors, French doors or bathroom windows that need a little privacy, patterned glass offers just that whilst retaining the natural light in the room.
Various finishes are available
The latest in a long line of innovation, Weatherfold 4s brings numerous new and exciting features, making it the smartest choice for exterior folding door hardware.
New locking mechanism with no loose parts. The new push button locking mechanism is a stand-out element and is consistent across all hangers and pivots. It has no loose parts that can be misplaced during installation.Featuring automatic locking technology, the system self locks as soon as the push button is released, ensuring that the panel always remains set. Available in four finishes,
Technical data – Folding doors
Softwood – Engineered Redwood
Hardwood – Engineered Meranti or Engineered European Oak
PROFILE AND CONSTRUCTION
Frame thickness IV68
COLOURS AND FINISH
High performance coatings in any standard RAL colour paint finish
Preservation micro porous, Paint / stain micro porous flow coat applied, 3 coats
Choice of twelve different stains
Dual colour option
For IV68 – Glazing D.G.U 24mm, 4mm/16mm gap swisspacer/4mm soft coat Low E, Uvalue 1.0W/M2k
Glaze gap Argon gas filled
Patterned (obscure) glass – optionalLaminated ot toughened (safe) and anti –burglary glass – optional
Colour availabe: RAL 7035 Standard
Optional: RAL 9016, RAL 9005, RAL 8003, RAL 8016, RAL 7035, RAL 7040
18mm, 20mm, 26mm, 60mm, lead bars
Internally beaded to prohibit removal of the glass from outside with concealed glazing pins
Silicone continuous neutral cure seal both sides
Q – Lon by Schlegel
HINGES AND LOCKS
Generally 7 – 8 weeks unless otherwise specified
Manufacturer has the right to introduce technical alterations without notifying.
The Brio 93HS Self Draining Sill is the perfect complement to Brio exterior folding door systems. It has been designed to integrate seamlessly with Brio Weatherfold 4s exterior folding door hardware. The aluminium tread makes it ideally suited to high traffic and high moisture contact environments. Mechanically fastened aluminium end caps feature a closed cell foam gasket to prevent water leakage. Water drains from the channel through predrilled drainage holes at the front of the sill.
• Suitable for residential and commercial applications
• Accommodates a panel thickness of 44.5mm and greater
• Two anti-crushing support webs support thejamb when screw fixing
• Aluminium tread
• Polypropylene channel
• 25 micron anodised finish in Clear or Bronze
• Available in 2m, 2.5m, 3m, 3.5m, 4m, 5m & 6m lengths
